GoldenEar ForceField 4 Subwoofer – Parts/Repair, Amp Needs Work
$150.00
Sold as-is for parts or repair — the amplifier board requires service and is not represented as working. What is good: the cabinet, very good cosmetically with its non-parallel walls intact; the custom front-firing 10-inch long-throw woofer, tested and working; and the 11 by 13 inch quadratic planar down-firing passive radiator, undamaged. GoldenEar supplies a replacement amplifier board through its service channel.
1 in stock
GoldenEar ForceField 4 Subwoofer – Parts/Repair, Amp Needs Work
Listed as-is for parts or repair: a GoldenEar ForceField 4 powered subwoofer with a very good cabinet and a known-good 10-inch woofer, but with an amplifier board that requires service. An honest, transparent listing for a technically minded buyer or repair shop looking to bring a serious GoldenEar sub back to life at a fraction of replacement cost.
The ForceField 4 is the popular mid-line GoldenEar powered subwoofer — a 1,200-watt-rated DSP-controlled design with a custom front-firing 10-inch long-throw woofer, an 11 x 13 inch quadratic planar down-firing passive radiator, and the elegant non-parallel-wall cabinet that gives the ForceField line its distinctive look and exceptionally low standing-wave behaviour. When working as designed, the ForceField 4 produces remarkably deep, tuneful bass for its compact footprint — but every ForceField is only as good as its amplifier, and the amplifier on this particular unit requires service.
Honest condition disclosure:
Cabinet: Very good cosmetic condition, no significant marks or damage
Woofer: Tested, in very good working condition
Passive radiator: Intact and undamaged
Amplifier board: Requires service — sold as-is, with no representation that the amplifier is functional in its current state
Best suited for: A technically capable buyer, a repair shop, or an existing ForceField 4 owner needing a parts donor (cabinet, woofer, radiator, grille, or feet)
Service options for the next owner:
A replacement amplifier board direct from GoldenEar is typically available through the company’s service channel, and is the cleanest path back to full original-spec performance
Independent repair to the existing board (capacitor replacement, output stage rework) is feasible for many of the common ForceField amplifier failure modes
The cabinet, woofer, and passive radiator are the costly, hard-to-replace parts in any subwoofer — having those in known-good condition is most of the value of the original unit
Specifications (as designed, for reference):
Built-in amplifier: 1,200-watt RMS digital with DSP frequency-shaping (currently requires service)
Driver: Custom front-firing 10 in. long-throw woofer
Passive radiator: 11 x 13 in. quadratic planar, down-firing
Frequency response: 14 – 250 Hz
High-pass filter (speaker-out): 150 Hz
Low-pass filter: 40 – 150 Hz, variable
Inputs: LFE line-level mono RCA, plus L/R speaker-level inputs
Outputs: L/R speaker-level outputs with built-in 150 Hz high-pass filter
Cabinet: Bass-reflex with non-parallel walls (narrower top, wider bottom)
Feet: Soft, energy-absorbing (originals included)
Dimensions (W x H x D): 13.375 x 13.125 x 17.875 inches (340 x 333 x 454 mm)
Weight: 32 lbs (14.5 kg)
A genuine high-value parts-or-repair opportunity — a complete GoldenEar ForceField 4 with a solid cabinet, working woofer, and intact passive radiator, priced specifically for a buyer who can address the amplifier issue and bring a USD $799 / CAD $1,200 sub back into service.
Sold as-is for parts or repair. No warranty applies to as-is parts/repair listings.
| Weight | 34 lbs |
|---|---|
| Dimensions | 22 × 18 × 17 in |
Related Products
Onkyo TA-2040 Cassette Deck – Silver, Japan, For Parts/Repair
Sold as-is for parts or repair: multiple faults, not covered by our warranty, not eligible for trade-back, all sales final. What it is, is a 1980 Japanese-built two-head deck with a sendust head, full-logic transport, FG-servo motor and Dolby B — not economic for our bench, and a completely different arithmetic if you have a soldering iron.
JVC SX-PW33 Slim Tower Subwoofer — 6.5in, 100W, High-Pass Out
A tall, narrow bass column meant to stand beside a cabinet rather than in front of it — 8.25 inches across the front and unusually deep at 17, which is the trade: the depth buys back the internal volume the narrow baffle gives away, so a 6.5 inch woofer is properly loaded in a strip of floor barely wider than a hardcover book. Driven by an integrated 100 watt amplifier, with speaker-level inputs and high-pass outputs so it works with an amplifier that has no subwoofer output at all. Good condition.
Yamaha RX-V1070 41lb! Natural Sound AVR *As-Is*
Sold as-is, for parts or repair, with no warranty and no trade-back. There is no sound output from any channel and the display is frozen; it has not been serviced. When it worked it was a 1993 flagship — 110 watts a channel at 0.015% distortion, Dolby Pro Logic, MM phono, pre-outs, and 41 lbs of it. For someone who repairs things.
Sony RCD-W3 Single Deck Playback – See Description
Sold as-is, and here is why: the left tray's laser has failed, so it will not record and will not play from that side. The right tray still plays CD, CD-R and CD-RW, and the digital outputs, analogue outputs and headphone jack with level control all work. That makes it a working CD player, a repair project, or parts. No returns, no warranty.
JVC RX-515V 5.1 AVR “AS IS” for Parts/Repair
