Pioneer PD-7700 Stable Platter CD Player – Made in Japan, CD-R
$295.00
An early-nineties Pioneer CD player in black, made in Japan and built around Pioneer's Stable Platter Mechanism, in very good condition, with a 1-bit DAC, an optical digital output and CD-R playback.
✔️ Very good condition — free of significant marks
✔️ Pioneer’s Stable Platter Mechanism and 1-bit DAC, made in Japan
✔️ Optical digital out, headphone jack, CD-R playback; universal remote included
✔️ Covered by Radique Warranty
✔️ Includes Perpetual Trade-Back Program eligibility
✔️ Expertly packed for safe shipping
Out of stock
This one has sold. Want first dibs on the next one?
We take these in regularly. Leave your name and email, and we’ll email you the moment one is listed, so you hear first. No cost, no obligation.
Email me when one is listed
How we get a component ready for sale. What our bench covers →
Read the full listing and see all 3 photos ↓
Other CD players we have in stock now
3 in stock · $175.00–$245.00 · all ship
NAD 513 3-Disc CD Changer – Original Remote, Serviced$245.00Ships
Denon DCM-420 5-Disc CD Changer Coax Out & Variable Out, Remote$225.00Ships
Sony CDP-CE375 5-Disc CD Changer — Optical Out | Play & Exchange$175.00ShipsHow we get a component ready for sale.
Before a used or vintage component is listed, it goes through our bench, and anything we service is tested again by a different tech. See exactly what our bench covers.
What our bench covers →An early-nineties Pioneer CD player in black, made in Japan and built around Pioneer’s Stable Platter Mechanism, in very good condition, with a 1-bit DAC, an optical digital output and CD-R playback.
What it is
Most CD players clamp a disc at its center and spin it label-side up, with the edges free to flutter. In the Stable Platter Mechanism, Pioneer turned that upside down. The disc sits label-side down on a full-size turntable platter that supports it across its whole surface, and the laser reads it from above. The disc spins flat and steady, with far less vibration reaching the pickup, which is why these players are still sought out today, both on their own and as transports feeding an outboard DAC.
The PD-7700 was built from 1990 to 1992. Conversion is handled by Pioneer’s 1-bit DAC, rated at 108 dB signal-to-noise and 102 dB channel separation. The analog outputs feed any amplifier or receiver, and the optical digital output connects to an external DAC, a receiver or a recorder. It plays the CD-Rs you have burned as well as pressed discs, and there is a headphone jack with its own volume control.
It sold new in Germany in 1991 for DM 550, about $750 in 2026 Canadian dollars.
This player has since been dressed in Ottawa Valley cherry. See it before and after on our Ottawa Valley Cherry Cabinetry page.
Condition
Very good, and free of significant marks, as the photographs show.
A Pioneer universal remote is included. It handles play, pause, skip, fast forward, rewind and direct track selection, and nothing more.
A Stable Platter Pioneer for the price of an ordinary CD player, and a fine transport for the DAC you already own.
Available for pickup in Kanata, or shipped across Canada and internationally — we have sent equipment to fifteen countries in the past year, each piece packed in-house in 275 lb test double-wall boxes. Live shipping rates for your address are calculated at checkout. Backed by Radique Audio’s Bumper-to-Bumper Warranty and our Perpetual Trade-Back Program. Available for audition by appointment in Kanata.
Pioneer PD-7700 Specifications
- Type: single-disc CD player, Pioneer Stable Platter Mechanism
- Converter: Pioneer 1-bit DAC
- Frequency response: 2 Hz – 20 kHz
- Signal-to-noise ratio: 108 dB
- Dynamic range: 97 dB
- Channel separation: 102 dB
- Total harmonic distortion: 0.0022%
- Outputs: analog RCA; optical digital (no coaxial); headphone jack with volume control
- Plays: CD and CD-R
- Remote: Pioneer universal remote (basic transport and track functions)
- Power: 120 V, 14 watts
- Finish: black
- Made in Japan, 1990–1992
- Dimensions: (Width x Height x Depth) 16.5 x 5.1 x 10.8 inches (420 x 130 x 274 mm)
- Weight: 9.3 lbs (4.2 kg)
🎚️ Gold Series RCA Interconnects
Our own Gold Series RCA Stereo Interconnect is a shielded, gold-plated stereo pair, in stock and ready to go. It is the cable that connects this to the rest of your system, and it is a straightforward upgrade on the free leads that come in the box with most equipment. 👉
⚠️ Important Information for International Buyers
This unit is configured for North American 110/120V power. Buyers outside North America will require a step-down transformer and appropriate plug adapter.
✅ Buy With Confidence — The Radique Promise
Backed by Radique Audio’s Bumper-to-Bumper Warranty and our Perpetual Trade-Back Program. When you’re ready to move on, we’ll take it back. That’s the Radique difference.
📦 Watch how we protect your gear — our unboxing video.
📺 Curious about our business? Check out our YouTube channel for behind-the-scenes videos and more!
📞 Questions? Use the Ask a Question button above, or call us at 613-416-9995.
| Weight | 11.3 lbs |
|---|---|
| Dimensions | 14.8 × 20.5 × 9.1 in |
Pioneer began in Tokyo in January 1938, when Nozomu Matsumoto set up shop around the A-8 speaker he had built the year before. By the late 1970s its SX receivers were at the heart of the hi-fi power race. We carry Pioneer stereo receivers and AV receivers, CD players, cassette decks, tuners and equalizers. We've had more than 240 Pioneer listings so far, covering 140 different models. Every used Pioneer here is inspected, tested and serviced as required, then photographed in-house and covered by our Bumper-to-Bumper Warranty and Perpetual Trade-Back Program. Don't see the model you want? Tell us on First Dibs and we'll email you when one arrives.
Pioneer is one of our two top-selling brands of vintage amps and receivers, along with Marantz. Our five best-selling Pioneer models so far: the SX-650, SX-750, SX-580, SX-780 and SX-680, all vintage stereo receivers from the 1976 and 1978 SX families. We also offer our custom cherry cabinets for these vintage Pioneers, hand-made from all-natural Ottawa Valley cherry, and we've upgraded dozens of Pioneers with them so far.
The Pioneer story, 1938 to today
Nozomu Matsumoto developed the A-8 speaker in 1937, and in January 1938 he set up Fukuin Shokai Denki Seisakusho in Tokyo. "Pioneer" was first the name of that speaker. Some histories give 1936 in Osaka as the start, but Pioneer dates itself to January 1938 in Tokyo. The company was incorporated in 1947 and renamed Pioneer Electronic Corporation in 1961.
Stereo and the US. In 1962 Pioneer introduced the PSC-5A, which it calls the first stereo with separate speaker cabinets, and its first PL turntables. Pioneer Electronics U.S.A. was founded in New York in 1966.
The power race. After a 1974 US Federal Trade Commission rule tightened how amplifier power was rated, receiver makers competed on watts. Pioneer's SX-1250 of 1976 was rated at 160 watts per channel, and the SX-1980 of 1978 to 1980 at 270.
CD and Elite. The P-D1 of 1982 was Pioneer's first CD player, and Elite-branded components were on sale by 1985.
Today. Pioneer sold its home audio business to Onkyo in 2015, keeping its car and DJ businesses, and Pioneer-branded home theatre gear was later made under licence. In December 2025 CarUX, part of Taiwan's Innolux, completed its purchase of Pioneer Corporation, which now focuses on in-car products.
Which Pioneer is which?
Early-1970s SX receivers: models such as the SX-424 to SX-828, rated at about 15 to 50 watts per channel.
The 1976 "x50" SX receivers: from the SX-450 at 15 watts per channel up to the SX-1250 at 160. Our best-selling SX-650 and SX-750 come from this family.
The 1978 "x80" SX receivers: including the SX-580, SX-680 and SX-780 we sell most, up to the SX-1980 flagship with quartz-lock tuning, which weighs more than 35 kg.
Spec and Exclusive separates: higher-end amplifiers such as the Spec-1 preamplifier (1976 to 1980) and the Exclusive C3/M3 pair (1974).
Elite: Pioneer's upper line from the mid-1980s, for example the PD-9010X CD player.
PL turntables, CT cassette decks and CD players: PL turntables from 1962, such as the PL-12 and the linear-tracking PL-L1; CT decks such as the three-head CT-F1000; and CD players from the 1982 P-D1 to magazine-loading changers such as the PD-M6.
Buying used Pioneer: what to check
Controls and switches. Crackle when you turn a control or work a switch usually means dirt, and restorers clean every pot and switch.
Capacitors. Electrolytic capacitors in 1970s receivers are often past their best, and full restorations replace them.
Big SX models. Owners and restorers report heat stress on the power-supply board of large receivers such as the SX-1250. Ask what has been done.
Relay, lamps and bias. The protection relay is a common replacement, dial lamps burn out and are often converted to LED, and restorers set the bias and DC offset.
Cassette decks. Check the heads, fast-forward and rewind, Dolby and every button. Belts age even when the deck looks perfect.
Everything we list is inspected, tested and serviced as required here, and comes with our warranty.
