Technics SU-V76 Vintage Integrated Amplifier – 100 WPC, Japan

$245.00

A 1987 New Class A integrated: pure Class A at low levels, sliding to Class A/B when the music asks for it, 100 watts a channel into 8 ohms at 0.05% distortion. It draws about 30 watts at idle, which is how you know the Class A bias is real rather than a label. MM phono and A/B speaker switching. Level 1 serviced; good cosmetic condition.

1 in stock

Description

Technics SU-V76 New Class A Integrated Amp 100 WPC — Made in Japan

Made in Japan, the Technics SU-V76 is a 1987-era “New Class A” integrated amplifier that has earned a reputation as a genuine sleeper among budget audiophiles — delivering 100 watts per channel into 8 ohms with Technics’ proprietary Class A biasing topology, which operates in pure Class A at lower power levels before seamlessly transitioning to Class A/B at higher output. The result is the warmth and musicality of Class A listening at everyday volumes, with the headroom and authority of a full 200-watt system when the music demands it.

The SU-V76’s power supply and output stage are built to punch above its price class. Large, heavily finned heat sinks handle thermal management passively — no fan noise to intrude on your listening — and the amplifier runs warm by design, a hallmark of its Class A bias current. At idle, the unit draws approximately 30 watts from the wall, confirming that meaningful Class A bias is present and working, not just a marketing label.

Inputs are comprehensive for a late-80s integrated: a moving magnet phono stage for turntable connection, plus tuner, auxiliary, and two tape loop inputs cover all analogue-era sources. Bass, treble, and balance controls are provided, along with speaker A/B switching for running two pairs of speakers. A full-sized headphone jack on the front panel rounds out the feature set.

This unit has undergone our Level One service and testing which should ensure many more years of reliable performance ahead. It is in good cosmetic condition with the classic Technics dark brown finish of the era.

Type: Stereo integrated amplifier, “New Class A”

Country of Manufacture: Japan

Power Output: 100W + 100W into 8Ω (stereo)

Total System Power: 200W

Frequency Response: 10 Hz – 80 kHz

Total Harmonic Distortion: 0.05%

Input Sensitivity: 2.5mV (phono MM), 150mV (line)

Signal-to-Noise Ratio: 71dB (phono MM), 97dB (line)

Inputs: Phono (MM), Tuner, Aux, Tape 1, Tape 2

Speaker Outputs: A + B (dual pair switching)

Headphone Output: Yes (front panel, 1/4″)

Tone Controls: Bass, Treble, Balance

Cooling: Passive (large finned heat sinks, no fan)

Finish: Dark brown

Year: 1987

Dimensions: (W x H x D) 16.9″ x 4.7″ x 10.0″ (430 x 119 x 255 mm)
Weight: 14.6 lbs (6.6 kg)

A Japanese-made “New Class A” integrated with 100 watts per channel, a built-in phono stage, and a reputation for punching well above its weight — freshly serviced and ready to deliver. Backed by Radique Audio’s Bumper-to-Bumper Warranty and Perpetual Trade-Back Program — shop with complete confidence.

$245.00
Additional information
Weight16.6 lbs
Dimensions14 × 21 × 8.7 in
About brand
Technics at Radique
We service Technics, too. Bring us your own Technics turntables, receivers, amplifiers, cassette decks and CD players for repair, servicing or restoration (not reel-to-reel decks), with a 90-day warranty on the work. See our Audio Service page

Technics is the premium audio name Matsushita (now Panasonic) created in Osaka in 1965, and its direct-drive turntables, above all the SL-1200, made it famous. We carry Technics turntables, stereo receivers, amplifiers, CD players, cassette decks and equalizers. We've had more than 160 Technics listings so far, covering more than 115 different models. Every used Technics here is inspected, tested and serviced as required, then photographed in-house and covered by our Bumper-to-Bumper Warranty and Perpetual Trade-Back Program. Turntables don't travel well by courier, so ours are pickup in Kanata or Curbside Delivery only. Don't see the model you want? Tell us on First Dibs and we'll email you when one arrives.

Our best-selling Technics models so far are two turntables, the SL-3200 and the SL-220.

The Technics story, 1965 to today

Matsushita Electric of Osaka created Technics in 1965 as its premium audio brand. The first product to carry the name was the Technics 1 bookshelf speaker.

Direct drive. The SP-10 of 1969 or 1970 (sources differ), built around a motor invented by Shuichi Obata, is what Technics calls the world's first direct-drive turntable. The SL-1200 followed in 1972 as a home hi-fi turntable, and the SL-1200MK2 of 1979 was redesigned with DJs in mind. About 3.5 million SL-1200s were made.

CD and the 1980s. The SL-P10 of 1982 was Technics' first CD player.

Pause and return. Panasonic ended SL-1200 production in 2010 and brought Technics back in 2014. A new SL-1200G arrived in 2016 and the SL-1200MK7 DJ model in 2019, and turntable production moved from Japan to Malaysia in 2021.

Which Technics is which?

SL-1200 and SL-1210: the MK2 of 1979 added quartz-locked speed control and a slider pitch control. The 1210 is the black version, often with dual-voltage switching.

SL-B, SL-D and SL-Q turntables: in the early-1980s range, Q models were fully automatic and quartz-locked, D models were not, and the SL-B models were belt-drive budget decks.

SL-3200, SL-220 and other home turntables: the Technics decks we sell most often.

SA receivers and SU amplifiers: such as the SA-1000 of 1978 to 1979. The SA-202 is one of the Technics receivers we've sold most.

RS tape decks, SL-P CD players and SB speakers: from the RS-1500U open-reel deck of 1976 to the SB-7000 linear-phase speakers of 1975.

Buying used Technics: what to check

Speed and pitch. On an SL-1200 or SL-1210, use the strobe to confirm the dots hold steady, and sweep the pitch fader at 33 and 45 rpm.

Tonearm. It should move smoothly with no play in the bearings, the headshell should clamp firmly, and the anti-skate, arm lock and cue lift should all work.

Connections. Loose leads cause crackling. Check the ground wire and both channels.

Everything we list is inspected, tested and serviced as required here, and comes with our warranty.
