Radique Audio Spade Connectors – Gold-Plated, Dual Set Screws
Price range: $15.00 through $120.00
Spades with a grip that holds: gold-plated solid brass, with two set screws on the wire.
- Fits binding posts up to 8 mm
- Red and black anodized jackets, non-conductive
- Takes 12 to 18 AWG; 13.3 g a spade
- Packs of 1, 2, 4 or 10 pairs
- 1-year warranty
Spades with a grip that holds
Solid brass, gold-plated, and held to the wire with two set screws, so the wire can’t back its way out. For binding posts where you want a flat, clamped contact.
The short answer
Radique Audio spade connectors are gold-plated solid brass speaker cable connectors that clamp under a binding post. Two set screws hold the wire, red and black anodized jackets mark polarity and won’t short if they touch, and each spade weighs 13.3 g. They take 12 to 18 AWG wire, fit posts up to 8 mm, measure 53 × 13 mm, and come in packs of 1, 2, 4 or 10 pairs.
Which connector does your gear need?
All four share the same red and black colour coding, so polarity reads at a glance whichever ends you choose. Not sure what your gear takes? Look at the terminals on the back, or send us the make and model.
| Connector | Made for | Wire | Sold as |
|---|---|---|---|
| Banana plugs | Standard 5-way binding posts (most amps and speakers) | 12–18 AWG | 1, 2, 4, 5, 7 or 14 pairs |
| Spade connectors (this one) | Larger binding posts, up to 8 mm | 12–18 AWG | 1, 2, 4 or 10 pairs |
| Pin connectors | Spring clips and guillotine terminals | 12–18 AWG | 1, 2, 4 or 10 pairs |
| Bi-wire bridges | Replacing jumper plates on bi-wire speakers | Pre-made, 12 in | A set of 4 |
What makes them better
Solid brass, gold-plated
Precision-machined solid brass, 13.3 g a spade, gold-plated against corrosion for a clean contact year after year.
Two set screws
Two screws grip the wire for a secure hold that single-screw and compression connectors can’t match.
Colour-coded, non-conductive
Red and black anodized jackets make polarity easy to read, even in low light, and can’t short if they touch.
Fits big posts
The fork fits binding posts up to 8 mm, and tightens down to a firm, flat contact.
Easy to fit
A standard screwdriver is all it takes.
Part of a matched set
Mix them with our banana plugs and pins for a cable with different ends.
Specifications
| Radique Audio spade connectors | |
|---|---|
| Spade | Gold-plated solid brass |
| Wire | 12 to 18 AWG (12 AWG is a tight fit) |
| Wire fixing | Dual set screws |
| Jacket | Anodized aluminum, colour-coded red and black, non-conductive |
| Size | 53 × 13 mm; fits posts up to 8 mm |
| Weight | 13.3 g per connector |
| Sold as | 1, 2, 4 or 10 pairs |
| Warranty | 1 year (Radique Audio) |
Why buy it from us
Audiophile quality, fair price
Radique Audio is our own line: parts we spec, test and use every day in our shop, priced the way we’d want to pay.
A 1-year warranty
Every Radique Audio product carries a 1-year warranty: if it fails under normal use within the year, we replace it at no charge.
Pick up, or have it shipped
Collect it free in Kanata by appointment, or have it shipped across Canada and internationally: enter your city and postal code on the cart page for live rates. With one of our pre-owned speakers or components, it rides along at no extra shipping cost.
Real help from people who use it
Not sure what fits? Send us the make and model of your gear and we’ll tell you, including when you don’t need anything at all.
On video
Meet the people behind Radique Audio
Our introduction video: who we are, how we work, and why we started making our own gear.
How we pack your order
Cables and connectors ship in our high-quality Radique Audio bubble packs. If your order also includes speakers or other larger gear, everything is boxed up together in our 275 lb-test double-wall packaging, as in this video.
Questions we get about this one
Will they fit your binding posts?
They fit posts up to 8 mm. Some vintage gear has posts too small for a full-size spade; for those, the small spade (fork) ends on our House CCA pairs and the Cable Builder are sized for #10 (M5) posts.
Will they fit your speaker wire?
They take 12 to 18 AWG. 18 to 14 AWG goes in easily; 12 AWG is a tight fit and goes in with care. Much thicker audiophile cable won’t fit; ask us and we’ll suggest an option.
How do they go on?
Strip the wire, twist the strands so none stray, slide it into the connector and tighten the two set screws with a small flat-head screwdriver. That’s all it takes.
Spades or bananas?
Both make a solid connection. Spades clamp under the post for a flat contact and suit larger posts; bananas push in and pull out without tools, handy if you swap gear often.
What warranty does it have?
A 1-year warranty, like every Radique Audio product: if it fails under normal use within the year, we replace it at no charge. See our warranty FAQ.
What does shipping cost? Is pickup possible?
Pickup in Kanata is free, by appointment. To have it shipped, add it to your cart and enter your city and postal code on the cart page: you’ll see live carrier rates before you commit. We ship across Canada and internationally. Buying it with one of our pre-owned speakers or components? Then it rides along in the same order at no extra shipping cost.
Do you ship to the United States?
Yes. On Radique Audio products we add the US import duties and fees at checkout and prepay them for you, so there’s nothing to pay at delivery.
Rather we built the whole cable?
Our Custom Speaker Cable Builder makes speaker cable to order, in any length, with these connectors on either end.
